PRO V Low Voltage Compact/Sandwich Type Bus Duct 50Hz/60Hz

PRO V Low Voltage Compact/Sandwich Type Bus Duct 50Hz/60Hz

Overview Product Description Pro V series busway integrates Wetown's high-quality product manufacturing technology, the

Send your inquiry

DESCRIPTION

Overview
Basic Info.
Model NO. Pro V
IP 54/66/68
Transport Package Fob/CIF/EXW
Specification CU/AL
Trademark WETOWN
Origin China
HS Code 8536909000
Production Capacity 70000m/Year
Product Description

Product Description

Pro V series busway integrates Wetown's high-quality product manufacturing technology, the latest global industrial design concepts, as well as innovative partitioned heat dissipation technology. The "Mirror Structure" design and "CGS integral grounding system" makes it more secure; The full-length compact design brings to safe and reliable power distribution system with smaller size. The meticulous protection design can achieve IP66. The whole shape adopts attractive industrial design, with "RAL7012" coating. It is suitable for power supply systems with 3P3W system, 3P4W system, 3P5W system, frequency 50~60Hz, rated working voltage up to 690V, rated insulation voltage up to 1000V, and rated working current 400~5000A. It has the features of stability and reliability, high power distribution effciency, excellent heat dissipation performance, low voltage-drop, high mechanical strength and convenient installation. "Know more about busway", Pro V series busway can be widely used in low-voltage power transmission and distribution systems for energy and infrastructure, industry, data centers, commercial and civil buildings, providing you with safety, convenience, stability, and energy saving and reliability. It's High-efficiency, environmental-friendly, intelligent and excellent busway system solutions, bring you reliable power supply, and serve as the intelligent power supply system, which can help to realize energy saving and effciency improving.

Operating environment
Place Indoor
Min ambient air temperature Indoor:-5ºC
Max ambient air temperature 40ºC
Average ambient air temperature daily 35ºC
Relative humidity Indoor:50%@40ºC
Pollution degree (of the installation environment) III
Altitude ≤2000m
Installation method Horizontal and vertical
