DESCRIPTION

Basic Info.

Model NO.	xlpe cable
Range of Application	Flame Retardant
Certification	ISO9001, CE
Brand	Jinshui
Transport Package	Drum
Specification	CE, ISO
Trademark	JINSHUI
Origin	China
HS Code	8544492100
Production Capacity	50000meter/Month

Product Description

XLPE /PVC (Cross-linked polyethylene) Insulated Electric Power Cable
Specifications

PVC/XLPE INSULATION POWER CABLE State Grid ISO 9001 Internation compliance Leading CABLE production base

Name: Copper Conductor XLPE Insulated Steel Wire Armored Power CableStandard: IEC60502, BS, DIN, ASTM, GB12706-2008 standard.Voltage: Up to 35KVConductor: Copper or Aluminum ConductorInsulation: PVC or XLPECross Section: Based on client's requirementApplication: Medium Voltage Power Cable is used in fixed laying to distribute the electricity in the AC rated voltage 35kV and under 35kV transmission line.Package: Wooden Drum Package or Iron-wooden drum

Three-core XLPE Insulated power Cable (8.7/10 8.7/15kv)
Nominal CrossSectionalAreamm2	Nominalinsulationthicknessmm	Approxoveralldiameterof cablemm	Approx weight of cableKg/km		Approxoveralldiameterof cablemm	Approx weight of cable Kg/km		Approxoveralldiameterof cablemm	Approx weight of cableKg/km		Approxoveralldiameterof cablemm	Approx weight of cableKg/km
			YJVYJV	YJLVYJLV		YJV22YJV23	YJLV22YJLV23		YJV32YJV33	YJLV32YJLV33		YJV42YJV43	YJLV42YJLV43
3x25	4.5	46	2380	1901	50	3406	2929	52	4745	4262	55	6203	5719
3x35	4.5	49	2818	2132	53	3896	3210	54	5381	4589	59	6824	6132
3x50	4.5	52	3299	2405	56	4441	3547	59	5935	5030	61	8195	7291
3x70	4.5	56	4117	2818	59	5342	4042	62	5942	5631	65	8713	7401
3x95	4.5	59	5155	3294	64	6557	4697	66	8230	6352	69	10085	8208
3x120	4.5	64	6317	3892	69	7896	5471	71	9715	7266	74	11720	9273
3x150	4.5	68	7303	4366	73	8971	6033	76	11692	8728	78	12915	9951
3x185	4.5	72	8405	4880	76	10179	5654	80	13234	8677	82	14498	10931
3x240	4.5	77	10323	5728	82	12272	7675	85	15496	10859	87	16828	12231
3x300	4.5	82	12658	6691	88	15673	9706	90	18234	12213	92	19689	13668
3x400	4.5	89	15195	7767	96	18830	11402	100	21035	13607	103	22440	15160
3x500	4.5	96	18305	9020	104	22267	12962	107	24589	15304	110
